automatic paver block machine

Name: automatic paver block machine
Brand: HI TECH ENGINEERING
Price: 2208400.0 INR
Availability: InStock

Price 2208400.0 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

automatic paver block machine Specification

Product Type
Color Paver, Fly Ash Bricks

Material
Concrete

Capacity
600 Pcs/hr

Weight (kg)
7 Metric Ton

Type
Other

Computerized
Yes

Automatic
Yes

PLC Control
Yes

Method
Hydraulic Pressure

Vibration Type
Mold Vibration

Vibration Frequency
35 Hertz (HZ)

Maximum Pressure
3000 PSI

Machine Power
30.5 Horsepower (HP)

Voltage
440 Watt (w)

Dimension (L*W*H)
225x112.5x80 Millimeter (mm)

Pallet Size
24 Inch x 21 Inch x 18 mm

Minimum Height
100 Millimeter (mm)

Maximum Height
8 Foot (ft)

Number of Bricks
6

Feature
Low Weight, Fire Resistant, High Durability

Color
yes

Warranty
12 Months

automatic paver block machine Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash in Advance (CID)

Supply Ability
2 Units, Unit Per Month

Delivery Time
60 Days

Sample Available
No

Packaging Details
Loose

Main Export Market(s)
Asia, Africa

Main Domestic Market
All India

Certifications
AN ISO 9001:2015 CERTIFIED COMPANY

automatic paver block machine About

Model No. HTC-1032

1. High Pressure Tonnage: 100 MT + 4 HP Mould Vibro Pressure, German Technology.

2. Total Power Require: 32.5 HP, 24.38 KW, 3 Phases.

3. Oil Tank Capacity: 400 Liter, Grade 68 No. Hydraulic Oil,

4. Production Capacity per Shift 8 Hour: Color Paver 4500 to 4800 / Bricks 11000 to 11500.

5. Block per Stock: 4 Paver Block or depend on design, 6 Bricks, 230 X 110 X 75mm or as per requirement.

6. System: Vibration with pressure, Oil Chiller, Pallet Auto Cut, Varam System, Magnetic System, Special Oil Filter, Feeding & Mould Gap Adjustable Plate, etc...

7. Auto Color Feeding: Auto Double Feeder Attachment for Top Layer / Color Paver

8. Pan Mixer: 6 Ft. 600 Kg Capacity, Heavy Duty (Roller & Blade), Powerful Worm Reduction Gear Box Transmission Unit.

9. Conveyor: Ft 30 X Width 18 Inch X Thickness 8mm, Dunlop or MRF Belt.

10. Color Mixer (Drum Type): Color Mixer for Top Layer of Paver Blocks.

11. Wheelbarrow Trolley: For Shifting raw material to Pan Mixture.

12. Auto Pallet Stacker: (Gear Type) For Shifting & Arranging Green Bricks Pallet from Press to pallet Truck or Stacker System (If require).

13. Automatic PLC: Fully Auto PLC operating all system & Warranted safety system with HMI Display.

14. Note: Specifications are subject to change for improvement.

State-of-the-Art Automation

Experience seamless paver block manufacturing with full automation and PLC control, designed to streamline operations and minimize manual intervention. The computerized interface enhances productivity and precision, making it suitable for extensive projects and continuous industrial use.

Durable and Efficient Design

Constructed for strength and resilience, this machine produces fire-resistant and highly durable concrete blocks. It operates at a vibration frequency of 35 Hz and utilizes hydraulic pressure up to 3000 PSI to ensure each block meets rigorous quality standards. The sturdy 7-ton build guarantees long-term reliability.

Versatility and Capacity

With the ability to produce up to 600 blocks per hour at various heights up to 8 feet, this machine accommodates diverse construction needs. The generous pallet dimensions and mold vibration mechanism facilitate consistent block shaping and efficient throughput, ideal for scaling up your production.

FAQ's of automatic paver block machine:

Q: How does the automatic paver block machine operate?

A: The machine uses PLC computerized controls to automate the production process. It employs a hydraulic pressure method combined with mold vibrations, allowing continuous and uniform block production with minimal manual involvement.

Q: What is the maximum capacity of this paver block machine?

A: This machine is capable of producing up to 600 concrete paver blocks per hour, making it suitable for high-volume manufacturing applications.

Q: When is it beneficial to use a fire-resistant, high-durability block machine?

A: Utilizing a machine that produces fire-resistant and highly durable blocks is essential when constructing infrastructure requiring long-lasting, resilient materials, such as pavements, industrial floors, or public spaces.

Q: Where can this paver block machine be installed?

A: The machine is designed for industrial and manufacturing facilities in India, with installation possible wherever appropriate utilities and space-such as factories or block yards-are available.

Q: What process does the machine use to form paver blocks?

A: Blocks are formed by compressing concrete under 3000 PSI using hydraulic pressure, with mold vibrations at 35 Hz ensuring each block is compact, uniform, and of high quality.

Q: How does computerized PLC control benefit users?

A: PLC control simplifies the operation by automating complex processes, reducing errors, enhancing consistency in production, and enabling quick adjustments for different block sizes or requirements.

Q: What is covered under the machine's 12-month warranty?

A: The warranty includes coverage for manufacturing defects and malfunctions arising during normal use, providing peace of mind and support for maintenance or necessary repairs within the first year.
